Performance Evaluation of Multi-ONU Customers Access Network using Spectrum Slicing and Duplication Techniques

This study aims to increase the number of access users by limiting the sample size to 30 users while ensuring that every Optical Network Unit (ONU) receives data from the Optical Line Terminal (OLT). The proposed solution allows for the determination of power requirements at each ONU based on bus-star topologies, facilitating an increase in user capacity. The power received by each ONU is a critical parameter that system designers must consider when planning the implementation of Fiber to the Home (FTTH), as it impacts the output data in terms of Bit Error Rate (BER) and Signal Quality Factor (QF) for each user. Various parameters were evaluated to ensure that the enhanced network improves scalability while adhering to standard specifications. These parameters included the Q-factor, BER, eye diagram, user count, and received power. The study employed slicing and duplication techniques, utilizing Arrayed Waveguide Grating (AWG) for signal duplication and Wavelength Division Multiplexing for signal slicing. The simulations were conducted using a transmitter operating at a frequency of 1491 nm with a power output of 0 dBm, utilizing the latest version of OptiSystem 20 software. The results highlighted the system's capability to support a total of 73,728 users, meeting stringent performance criteria. Specifically, the system achieved a Q-factor greater than 6, indicating high signal quality, and a bit error rate (BER) lower than 1 × 10-9, ensuring reliable data transmission. For the sampled 30 users, the average Q factor was 8.1527, and the average BER was 5.3648 × 10^-11, with an output power level of -54.278 dBm. Despite an increase in users, the quality of the data supplied to clients remained unchanged. These outcomes underscore the robustness and efficiency of the design in delivering high-capacity, error-resilient optical communication. © 2025 Institute of Physics Publishing. All rights reserved.
